Zirconium 702 / 704 / 705 Werkstoff Nr. 2.7025 / 2.7040 / 2.7055 Hex Head Bolts, Fasteners Manufacturer, Exporter & Suppliers
ASTM B493 / B550 / B551 Zirconium Alloy UNS No. R60702 / R60704 / R60705 Bolts, Nuts, Washers, Hex Bolts, Socket Screw Suppliers in India
‘In its essence Zirconium is a highly corrosion-resistant metal known for its exceptional resistance to acids, alkalis, and aggressive chemical environments. It, unlike conventional stainless steel fasteners, offers high performance for applications involving corrosive environments. These include hydrochloric acid, sulfuric acid, and organic acid processing systems.
We at Fasteners and Fixtures LLP, a leading Zirconium manufacturer in Mumbai, provide a comprehensive range of zirconium bolts, zirconium nuts, zirconium washers, and custom zirconium fasteners manufactured to international quality standards. One of our major goal is to provide for your business fastening solutions that are engineered for durability, reliability, and long service life, even in the most challenging industrial conditions.
Our focus fastening solutions are engineered for durability, reliability, and long service life, even in the most challenging industrial conditions. More importantly, as a top Zirconium manufacturer in Mumbai we are seeking to focus on precision manufacturing, strict quality control, and global export capabilities. So, if you are looking to get zirconium fasteners of Premium Quality for unmatched corrosion resistance, enhanced safety, and long-term operational efficiency in critical industrial applications then, you need to ‘Get in Touch’ with us at Fasteners and Fixtures LLP today.
Specification
|
Material
|
Size
|
Length
|
Specification
|
|---|---|---|---|
|
Zirconium
|
M02 to M100 |
3 mm |
ASME DIN ASTM |
|
Material
|
Carbon Steel, Mild Steel, EN8, EN19, EN24, 4140, 4340, High Tensile Steel Etc.
|
|
Standard
|
ASTM A307 / A325 / A490 / A193 / A194 / IS 1367 / IS 1364 / DIN 931 / DIN 933 / DIN 976 |
|
Carbon Steel in Grade
|
UNS 2200 (NICKEL 200) / UNS 2201 (NICKEL 201), UNS 4400 (Monel 400), UNS 8825 (INCONEL 825), UNS 6600 (INCONEL 600) / UNS 6601 (INCONEL 601), UNS 6625 (INCONEL 625), UNS 7718 (INCONEL 718), UNS 10276 (HASTELLOY C 276), UNS 8020 (ALLOY 20 / 20 CB 3) |
|
Type of Fasteners
|
Bolts : Bolts stud bolts, hex head bolts, socket hexagon head screw anchor bolts, u-bolts, J bolts, mushroom head square neck bolts, t- head bolts, wing screw, eye bolt, eye bolt, foundation bolts and structural bolts Washer : Plain washer , plain big & small OD washer , spring lock washer , spring washer heavy duty , tooth washer , star washer , tab washer with one & two tab Nuts : Hexagon nuts, hexagon coupling nuts, hexagon thin nut, square nut, hexagon castle nuts, self locking nut, hexagon domed cap nuts
Screw : Pan head slotted screws, cheese head slotted screws, countersunk head slotted screws, countersunk raised head slotted screws, pan phillipse head screw, countersunk Phillipse raised head screws, slotted cheese trim head machine screws, socket head allen cap screws, allen countersunk socket head cap screws, socket head shoulder screws, socket head cap screw low head, hexagon socket set screw with flat point, hexagon socket set screws with cone point, hexagon socket set screw with dog point, hexagon socket set screws with dog point, hexagon socket set screws with cup point, imprial socket cap screws. Other : Threaded rod, as per drawing and customers spec. coating, hot dipped galvanizing, phosphate, Teflon, xylon, zinc, cadmium.
|
|
In Form of
|
Hex, Square, Round , Threading as per Gauge Etc. |
Zirconium Fasteners Useful Info
Grade Designation
| Grade | UNS Number | Werkstoff No. (DIN) |
| Zirconium 702 | R60702 | 2.7025 |
| Zirconium 704 | R60704 | 2.7040 |
| Zirconium 705 | R60705 | 2.7055 |
Chemical Properties :
Typical compositional ranges for Ziconium Fasteners
| Element (%) | Zirconium 702 | Zirconium 704 | Zirconium 705 |
| Zr + Hf (min) | 99.2 | 97.5 | 95.5 |
| Hafnium (Hf) | 4.5 max | 4.5 max | 4.5 max |
| Iron (Fe) | 0.2 max | 0.2 max | 0.2 max |
| Chromium (Cr) | 0.1 max | 0.1 max | 0.1 max |
| Oxygen (O) | 0.16 max | 0.18 max | 0.18 max |
| Nitrogen (N) | 0.025 max | 0.025 max | 0.025 max |
| Carbon (C) | 0.05 max | 0.05 max | 0.05 max |
| Hydrogen (H) | 0.005 max | 0.005 max | 0.005 max |
| Tin (Sn) | – | 1.0 – 2.0 | – |
| Niobium (Nb) | – | – | 2.0 – 3.0 |
Mechanical Properties :
Typical compositional ranges for Zirconium Fasteners
| Property | Zirconium Grade 702 | Zirconium Grade 704 | Zirconium Grade 705 |
| UNS Number | R60702 | R60704 | R60705 |
| Type | Commercially Pure | Commercially Pure (High Strength) | Zirconium Alloy (Nb Added) |
| Tensile Strength (Min) | 379 MPa | 413 MPa | 552 MPa |
| Yield Strength (0.2% Offset) | 207 MPa | 241 MPa | 379 MPa |
| Elongation (Min) | 16% | 14% | 16% |
| Reduction of Area | 35–40% | 30–35% | 25–30% |
| Hardness (HB) | ~200 HB | ~220 HB | ~250 HB |
| Modulus of Elasticity | 99 GPa | 99 GPa | 99 GPa |
| Shear Modulus | 33 GPa | 33 GPa | 33 GPa |
| Poisson’s Ratio | 0.34 | 0.34 | 0.34 |
| Impact Strength | Excellent | Very Good | Good |
| Fatigue Strength (10⁷ cycles) | ~200 MPa | ~220 MPa | ~300 MPa |
General Queries asked when buying Zirconium Fasteners
- Types of Zirconium Grading
- Specifications of Zirconium
- Dimensions of Zirconium
- Quality Testing used for Zirconium
- Manufacturing process of Zirconium
- Packaging of Zirconium
- Compliance certificates used
- Pricing type
Why do you need to choose Fasteners and Fixtures LLP to buy Zirconium?
There are many industries that require materials which have high corrosion resistance, strength, and durability, and Zirconium proves to be the best option. From chemical processing plants to nuclear power facilities, Zirconium delivers exceptional performance in high hostile temperatures.
More importantly, if you are looking for reliable partner who can offer your Premium Quality Zirconium at an affordable Zirconium Price in India, then you need to choose us at Fasteners and Fixtures LLP, a leading Zirconium Manufacturer in India for the following reasons given below:
- Provision of High-Quality Zirconium Materials with Certified Standards
- Exceptional Corrosion-Resistant Solutions
- Offering of competitive pricing with transparent quotations
- Customised Manufacturing Capabilities
- Strong Technical Support and Customer Assistance availability
- Trusted Reputation in the Industry
